The primary goal of an Epoxy Dispenser system is to infuse a consistent as well as a manageable amount of glue right into the ferrule as well as port. The truth is that many 2-part epoxies used in fiberoptic terminations have a working life in the series of hrs, and also the epoxy thickness will slowly rise throughout that time, creates obstacles to control the epoxy shot process, regardless of dispensing technique.
A “correct” epoxy giving process needs to take into consideration the following:
The entire ferrule-hole bore must be completely filled with epoxy.
In many dispensing procedures, this is accomplished by infusing epoxy up with the back-end of the ferrule, up until a tiny grain of epoxy leaves on the ferrule end-face (the “epoxy bead”). Less typical is the use of a vacuum system to “draw” epoxy at the back-end of the ferrule via the ferrule bore, till it departures on the ferrule end-face. Both accomplish the same objective.
The back-end of the ferrule (where it is pressed right into the ferrule-holder) needs to have enough epoxy fill to make sure the fiber strip point can be totally encapsulated with epoxy.
Too little epoxy, or big voids in the epoxy, might trigger the fiber to not be fully enveloped, substantially enhancing the risk of fiber breakage.
The “Epoxy Injection” process in a cord production line is one that calls for robust process controls, as it is virtually difficult to verify the efficiency of the shot (correct ferrule fill) with subsequent screening– if there is not nearly enough epoxy injected into the ferrule, the only method to figure out is via destructive screening (i.e. cross-sectioning) or item failing.
Of course, the hands-on epoxy shot can be fairly labor-intensive and also is a “skill” that requires adequate training and surveillance. Consequently, factories may gain from purchasing more pricey dispensing systems that minimize labor while boosting epoxy fill control, which results in lower scrap and also an extra trustworthy product.
Automated giving systems
Pneumatically driven or displacement dispensers can be utilized with robotic positioning systems to implement an automatic dispensing system. Such a scheme requires an operator to pack the syringes and to place the dispensers or “weapons” in the robot positioner, however, it can accomplish a considerable decrease in operator time and staffing requires at a large operation. Once the system is packed, a driver can move on to filling other terminals or various other jobs.
Robotic systems conserve labor, but the actual Epoxy Dispenser method is still either pneumatically driven or displaced. Some robotics incorporate vision systems to make sure placement when inserting the needle into the ferrule’s back hole. Others utilize specific placing systems. These systems add to prices, so an assembly firm needs large-quantity orders with specific adapter kinds to take full advantage of robot dispensing.
