Is It Required to Clean No Clean Flux?

Most assemblers in the digital market use no-clean solder paste primarily to eliminate the demand of cleaning up the circuit board assemblies.

No Clean Flux are low solid (less than 5%) fluxes, specifically created for smds and blended technology soldering. They are totally non-halide, reveal exceptional solderability on all types of board consisting of smds, offer exceptional moistening on surface installed parts, and also leave no noticeable change residue after soldering. Typically no more cleaning is needed, yet if extremely high ionic cleanliness is needed, the deposit can be eliminated by solvent or saponification cleaning. These changes are j-std-004 compliant.

Most assemblers in the digital industry use no-clean solder paste mainly to remove the need to cleanse the circuit-board assemblies. Makers such as Thrill PCB choose to run all manufacturing with the same procedure and, for that reason, additionally use no-clean flux, for which they have actually created and fine-tuned their assembly processes. Assemblers prefer to cleanse only the printed-circuit boards (PCBs) that require it rather than adjusting procedures that accommodate different sorts of solder paste.

No-clean solder paste typically doesn’t need cleaning. Assemblers find it more difficult to remove the change residue that no-clean pastes leave behind, as contrasted to flux from other types of solder pastes. Cleaning such trace residue creates an issue, since their styles do not enable them to wash off quickly

In truth, no-clean solder paste leaves flux with reduced deposit. The reflow process leaves trace amounts of resinous residue, non corrosive in nature. Existing on or around solder joints, the residue can vary in color from brownish-yellow to clear. The residue left on the board after reflow depends straight on the solid content in the solder paste, primarily composed of activators, gelling representatives, as well as materials.

Why No Clean Flux

Issues taking place throughout in-circuit testing caused assemblers considering cleansing boards soldered with no-clean paste. Earlier generations of no-clean pastes created gaudy residues after reflow, and examination pins didn’t constantly pass through fully to make great electrical contact with corresponding test pads. In addition, pins had residue building up on them that affected their accuracy, requiring periodic maintenance. Nevertheless, the most up to date generation of no-clean pastes do not experience these problems.
Although development of No Clean Flux was to stay clear of the need for cleaning PCBs post-reflow, they currently represent one of the best difficulties in cleaning PCBs. No-clean fluxes contain salt activators that when being available in contact with other chemicals as well as in the existence of warmth, develop a creamy colored residue, helping to corrode delicate circuitry and allowing development of dendrites.
